High Dielectric Constant Type X5R(R6) Characteristics Low Profile
LxW [mm]
1.0x0.5(15)<0402>
25(1E)
Rated Volt. [Vdc]
Capacitance
220pF(221)
16(1C)
16(1C)
Tolerance
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
Part Number
330pF(331)
470pF(471)
680pF(681)
1000pF(102)
1500pF(152)
2200pF(222)
3300pF(332)
4700pF(472)
6800pF(682)
10000pF(103)
LxW [mm]
1.6x0.8(18)<0603>
Rated Volt. [Vdc]
Capacitance
1.0µF(105)
16(1C)
10(1A)
Tolerance
Part Number
GRM185R61C105KE44D* GRM185R61A105KE36D*
±10% (K)
LxW [mm]
2.0x1.25(21)<0805>
Rated Volt. [Vdc]
Capacitance
6800pF(682)
33000pF(333)
68000pF(683)
0.22µF(224)
0.33µF(334)
0.47µF(474)
0.68µF(684)
1.0µF(105)
100(2A)
50(1H)
25(1E)
16(1C)
Tolerance
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
Part Number
GRM216R61E105KA12D
2.2µF(225)
GRM219R61E225KA12D* GRM219R61C225KA88D*
GRM219R61C475KE15D*
4.7µF(475)
LxW [mm]
2.0x1.25(21)<0805>
6.3(0J)
Rated Volt. [Vdc]
Capacitance
4.7µF(475)
10(1A)
4(0G)
Tolerance
±10% (K)
±10% (K)
±20% (M)
Part Number
GRM219R61A475KE34D*
GRM219R61A106KE44D*
10µF(106)
GRM219R60J106KE19D*
22µF(226)
GRM219R60G226ME66D*
The part number code is shown in ( ) and Unit is shown in [ ].
: Please refer to X7R(R7) etc Characteristics.
< >: EIA [inch] Code
*: Please refer to GRM Series Specifications and Test Method(2).
