Continued from the preceding page.
5. DC Voltage and AC Voltage Characteristic
1. The capacitance value of a high dielectric constant type
capacitor changes depending on the DC voltage applied.
Please consider the DC voltage characteristics when a
capacitor is selected for use in a DC circuit.
1-1. The capacitance of ceramic capacitors may change
sharply depending on the applied voltage. (See
figure)
[DC Voltage Characteristics]
20
0
-20
-40
-60
-80
-100
Please confirm the following in order to secure the
capacitance.
(1) Whether the capacitance change caused by the
applied voltage is within the range allowed or not.
(2) In the DC voltage characteristics, the rate of
capacitance change becomes larger as voltage
increases. Even if the applied voltage is below
the rated voltage. When a high dielectric constant
type capacitor is in a circuit that needs a tight
(narrow) capacitance tolerance. Example: a time
constant circuit., please carefully consider the
characteristics of these capacitors, such as their
aging, voltage, and temperature characteristics.
And check capacitors using your actual
0
1
2
3
4
5
6
7
DC Voltage (VDC)
8
appliances at the intended environment and
operating conditions.
2. The capacitance values of high dielectric constant type
capacitors change depending on the AC voltage
applied.
[AC Voltage Characteristics]
30
20
Please consider the AC voltage characteristics when
selecting a capacitor to be used in a AC circuit.
10
0
-10
-20
-30
-40
-50
-60
0.0
0.5
1.0
1.5
2.0
2.5
AC Voltage (Vr.m.s.)
6. Capacitance Aging
1. The high dielectric constant type capacitors have the
characteristic in which the capacitance value decreases
with passage of time.
20
10
When you use a high dielectric constant type capacitors
in a circuit that needs a tight (narrow) capacitance
tolerance. Example: a time constant circuit., please
carefully consider the characteristics of these capacitors,
such as their aging, voltage, and temperature
characteristics. And check capacitors using your actual
appliances at the intended environment and operating
conditions.
0
-10
-20
-30
-40
5C
R∆
10
100
1000
10000
Time (Hr)
Continued on the following page.
