Temperature Compensating Type C0G(5C) Characteristics
LxW [mm]
3.2x2.5(32)<1210>
Rated Volt. [Vdc]
Capacitance
110pF(111)
500(2H)
300(YD)
250(2E)
100(2A)
Tolerance
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
Part Number
ERB32Q5C2H111GDX1L
ERB32Q5C2H111JDX1L
ERB32Q5C2H121GDX1L
ERB32Q5C2H121JDX1L
120pF(121)
130pF(131)
150pF(151)
160pF(161)
180pF(181)
200pF(201)
220pF(221)
240pF(241)
270pF(271)
300pF(301)
330pF(331)
360pF(361)
390pF(391)
430pF(431)
470pF(471)
ERB32Q5CYD131GDX1L
ERB32Q5CYD131JDX1L
ERB32Q5CYD151GDX1L
ERB32Q5CYD151JDX1L
ERB32Q5C2E161GDX1L
ERB32Q5C2E161JDX1L
ERB32Q5C2E181GDX1L
ERB32Q5C2E181JDX1L
ERB32Q5C2E201GDX1L
ERB32Q5C2E201JDX1L
ERB32Q5C2E221GDX1L
ERB32Q5C2E221JDX1L
6
ERB32Q5C2A241GDX1L
ERB32Q5C2A241JDX1L
ERB32Q5C2A271GDX1L
ERB32Q5C2A271JDX1L
ERB32Q5C2A301GDX1L
ERB32Q5C2A301JDX1L
ERB32Q5C2A331GDX1L
ERB32Q5C2A331JDX1L
ERB32Q5C2A361GDX1L
ERB32Q5C2A361JDX1L
ERB32Q5C2A391GDX1L
ERB32Q5C2A391JDX1L
ERB32Q5C2A431GDX1L
ERB32Q5C2A431JDX1L
ERB32Q5C2A471GDX1L
ERB32Q5C2A471JDX1L
LxW [mm]
3.2x2.5(32)<1210>
50(1H)
Rated Volt. [Vdc]
Capacitance
510pF(511)
Tolerance
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
±2% (G)
±5% (J)
Part Number
ERB32Q5C1H511GDX1L
ERB32Q5C1H511JDX1L
ERB32Q5C1H561GDX1L
ERB32Q5C1H561JDX1L
ERB32Q5C1H621GDX1L
ERB32Q5C1H621JDX1L
ERB32Q5C1H681GDX1L
ERB32Q5C1H681JDX1L
ERB32Q5C1H751GDX1L
ERB32Q5C1H751JDX1L
ERB32Q5C1H821GDX1L
ERB32Q5C1H821JDX1L
ERB32Q5C1H911GDX1L
ERB32Q5C1H911JDX1L
ERB32Q5C1H102GDX1L
ERB32Q5C1H102JDX1L
560pF(561)
620pF(621)
680pF(681)
750pF(751)
820pF(821)
910pF(911)
1000pF(102)
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
