■ Specifications and Test Methods
No Item
Specification
Test Method（Ref. Standard:AEC-Q200）
Appearance
Capacitance
Q or D.F.
No defects or abnormalities.
Per MIL-STD-202 Method 215
10 Resistance to Solvents
Within the specified initial value.
Within the specified initial value.
Within the specified initial value.
I.R.(Room Temp.)
Appearance
Capacitance
Q or D.F.
No defects or abnormalities.
Mounting method
Waveform
Peak value
Solder the capacitor on the test substrate
Half-sine
1500g
11 Mechanical Shock
Within the specified initial value.
Within the specified initial value.
Within the specified initial value.
I.R.(Room Temp.)
Holding Time
0.5ms
Velocity change
Shocks directions and times
4.7m/s
Three shocks in each direction should be applied along 3
mutually perpendicular axes of the test specimen (18 shocks).
Appearance
Capacitance
Q or D.F.
No defects or abnormalities.
Mounting method
Kind of Vibration
Vibration Time
Solder the capacitor on the test substrate
A 10Hz to 2000Hz to 10Hz
20min
1.5mm
12 Vibration
Within the specified initial value.
Within the specified initial value.
Within the specified initial value.
I.R.(Room Temp.)
Total amplitude
Vibration directions and time
This motion should be applied for 12 items in each 3 mutually perpendicular directions
(total of 36 times).
Appearance
Capacitance or Capacitance Change
No defects or abnormalities.
Pre-treatment
Heat treatment:Perform a heat treatment at 150+0/-10°C for 1hour and then let sit for 24+/-2hours
at room temperature, then measure.
Solder bath method
Sn-3.0Ag-0.5Cu(Lead Free Solder)
260+/-5℃
10+/-1s
13 Resistance to Soldering
Heat
Capacitance:Within the specified initial value.
Within the specified initial value.
Within the specified initial value.
Q or D.F.
I.R.(Room Temp.)
Test Method
Kind of Solder
Test Temperature
Test Time
Post-treatment
Non treatment:Let sit for 24+/-2hours at room temperature, then measure.
Appearance
Capacitance
Q or D.F.
No defects or abnormalities.
Per AEC-Q200-002
Post-treatment
14 ESD
Within the specified initial value.
Within the specified initial value.
Within the specified initial value.
Heat treatment:Perform a heat treatment at 150+0/-10°C for 1hour and then let sit for 24+/-2hours
at room temperature, then measure.
I.R.(Room Temp.)
95% of the terminations is to be soldered evenly and continuously.
Pre-treatment
Flux
Kind of Solder
Solder Temperature
Immersion time
Immersion and emersion rate
Perform a heat treatment at 155°C for 4hours.
Solution of rosin ethanol 25(mass)%
Sn-3.0Ag-0.5Cu(Lead Free Solder)
Sn-3.0Ag-0.5Cu solder solution at 245+/-5 ℃
5+0/-0.5s
15 Solderability (a)
25+/-5mm/s
Measurement Temperature
Shown in Rated value.
25℃
16 Capacitance
Measurement Frequency 1.0+/-0.1kHz
Measurement Voltage
1.0+/-0.2Vrms
Measurement Temperature
DF≦0.05
25℃
17 Q or Dissipation Factor
(D.F.)
Measurement Frequency 1.0+/-0.1kHz
Measurement Voltage
1.0+/-0.2Vrms
GCJ216R72A222MA01-02D
4
