6880 Series
Spectrum Cleanup Filter: 5.0MHz to 150 MHz
•ꢀ Proportional bandwidth 2-pole
crystalꢀfilterꢀ-ꢀ3dBꢀpassbandꢀ&ꢀ
15dBꢀstopbandꢀwidenꢀproportionalꢀ
to center frequency
•ꢀ LowꢀSSBꢀphaseꢀnoiseꢀ(-122dBc/
Hzꢀ@ꢀ10Hzꢀoffset,ꢀ-132dBc/Hzꢀ@ꢀ
100Hzꢀoffsetꢀandꢀ-132dBc/Hzꢀ@ꢀ
1000Hz offset)
•ꢀ Applicationsꢀwhereꢀclock/timingꢀ
chainꢀsignalꢀnoiseꢀreductionꢀisꢀ
primaryꢀgoal
Theꢀorderingꢀconventionꢀforꢀaꢀconnectorizedꢀ6880ꢀSeriesꢀfiltersꢀwithꢀSMA-Femaleꢀconnectorsꢀonꢀbothꢀtheꢀinputꢀandꢀoutputꢀ
wouldꢀbeꢀ6880VBMꢀ@ꢀ100.00MHz.ꢀForꢀother,ꢀmostꢀpopularꢀconnectorꢀtypes,ꢀreferenceꢀtheꢀtableꢀandꢀforꢀothersꢀnotꢀlistedꢀ
consultꢀtheꢀfactory.
6880 Connectorized Package
6880 F Package
(2 pole F case)
(50Ω Terminated)
MtronPTI reserves the right to make changes to the product(s) and service(s) described herein without notice. No liability is assumed as a result of their use or application.
Please see www.mtronpti.com for our complete offering and detailed datasheets. Contact us for your application specific requirements: MtronPTI 1-800-762-8800.
Revision: 8-10-07
