MP6922A—DUAL, FAST-TURN–OFF, INTELLIGENT RECTIFIER
ORDERING INFORMATION
Part Number
Package
SOIC8
Top Marking
MP6922AGSE*
MP6922A
SOIC8E
SOIC14
MP6922AGN**
MP6922AGS***
MP6922A
MP6922A
*For Tape & Reel, add suffix –Z (e.g. MP6922AGSE–Z);
**For Tape & Reel, add suffix –Z (e.g. MP6922AGN–Z);
***For Tape & Reel, add suffix –Z (e.g. MP6922AGS–Z);
PACKAGE REFERENCE
ABSOLUTE MAXIMUM RATINGS (1)
VDD to VS1,VS2, VSS ........................-0.3V to +26V
PGND to VS1,VS2, VSS...................-0.3V to +0.3V
Recommended Operation Conditions (3)
VDD to VS1,VS2, VSS...............................8V to 24V
Operating Junction Temp. (TJ). -40°C to +125°C
Thermal Resistance (4)
SOIC8 .....................................90 ...... 45...°C/W
SOIC8E...................................50 ...... 10...°C/W
SOIC14 ...................................86 ...... 38...°C/W
θJA
θJC
V
G1 to VS1, VSS................................. -0.3V to VDD
VG2 to VS2, VSS................................. -0.3V to VDD
VD1 to VS1, VSS .............................-0.7V to +180V
VD2 to VS2, VSS .............................-0.7V to +180V
LL, EN to VS1,VS2, VSS ..................-0.3V to +6.5V
Maximum Operating Frequency............ 300 kHz
Notes:
1) Exceeding these ratings may damage the device.
(2)
Continuous Power Dissipation.. (TA = +25°C)
2) TA=+25℃. The maximum allowable power dissipation is a
SOIC8........................................................ 1.4W
SOIC8E...................................................... 2.5W
SOIC14...................................................... 1.5W
Junction Temperature...............................150°C
function of the maximum junction temperature TJ (MAX), the
junction-to-ambient thermal resistance θJA, and the ambient
temperature TA. The maximum allowable continuous power
dissipation at any ambient temperature is calculated by PD
(MAX) = (TJ (MAX)-TA)/θJA. Exceeding the maximum allowable
power dissipation will cause excessive die temperature, and
the regulator will go into thermal shutdown. Internal thermal
shutdown circuitry protects the device from permanent
damage.
Lead Temperature (Solder).......................260°C
Storage Temperature .............. -55°C to +150°C
3) The device is not guaranteed to function outside of its
operating conditions.
4) Measured on JESD51-7, 4-layer PCB. Without heatsink.
MP6922A Rev. 1.02
11/30/2012
www.MonolithicPower.com
MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
© 2012 MPS. All Rights Reserved.
