MSS0271
Preliminary
MOSEL VITELIC INC.
Timing Diagram
I. Edge Trigger Mask
I.1. Unholdable output with BUSY
a. When trigger is shorter than output
b. When trigger is longer than output
TG
AUDIO
BUSY
I.2. Unholdable output with Fixed-Type LED Flasher
a. When trigger is shorter than output
b. When trigger is longer than output
b. When trigger is longer than output
TG
AUDIO
LED
I.3. Unholdable output with Dynamic-Type LED Flasher
a. When trigger is shorter than output
TG
AUDIO
LED
I.4. Holdable output with BUSY
a. When trigger is shorter than a whole section output
b. When trigger is longer than a whole section output
TG
AUDIO
BUSY
I.5. Holdable output with Fixed-Type LED Flasher
a. When trigger is shorter than a whole section output b. When trigger is longer than a whole section output
TG
AUDIO
LED
I.6. Holdable output with Dynamic-Type LED Flasher
b. When trigger is longer than a whole section output
a. When trigger is shorter than a whole section output
TG
AUDIO
LED
I.7. Unholdable output with Retrigger
a. When trigger is shorter than a whole section output
b. When trigger is longer than a whole section output
TG
AUDIO
Specifications subject to change without notice, contact your sales representatives for the most recent information.
PID257*** 05/97
8/12
