This document was generated on 03/31/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
0673298020
Active
Description:
Universal Serial Bus (USB) Shielded I/O Receptacle, Type A, Single Upright Right
Angle, Solder Tail Length 2.00mm (.079"), 3.65mm (.144") Beveled Metal Pins, PCB
Thickness 1.60mm (.062"), Gold (Au) Flash, Lead Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-89485 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
China RoHS
Agency Certification
UL
E29179
EU RoHS
General
Product Family
Series
Application
Comments
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
I/O Connectors
67329
Wire-to-Board
Standard Mount Type|Beveled Metal Pin Length:
3.65mm (.144")
Not Reviewed
Need more information on product
environmental compliance?
Component Type
Product Name
Type
Receptacle
USB
A
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Physical
Boot Color
N/A
4
Circuits (Loaded)
Circuits (maximum)
Flammability
Gender
Lock to Mating Part
Material - Plating Mating
Material - Plating Termination
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
4
Please visit the Contact Us section for any
non-product compliance questions.
94V-0
Receptacle
Yes
Gold
Tin
Search Parts in this Series
67329Series
4
Upright
0.079 In
2.00 mm
Yes
Mates With
USB Type A Plug
PCB Retention
Yes
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
0.063 In
1.60 mm
Tray
Panel Mount
No
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Pitch - Term. Interface (in)
Pitch - Term. Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Polarized to Mating Part
Polarized to PCB
0.000 In
0.00 mm
0.055 In
1.40 mm
4
0.1
100
2.5
Yes
Yes
Ports
1
Surface Mount Compatible (SMC)
Termination Interface: Style
Waterproof / Dustproof
Yes
Through Hole
No
