MITSUBISHI <INTELLIGENT POWER MODULES>
PM30CNJ060
FLAT-BASE TYPE
INSULATED PACKAGE
CONTROL PART
Limits
Unit
Symbol
Parameter
Circuit Current
Input ON Voltage
Test Condition
VD = 15V, VCIN = 15V
Min.
—
Typ.
18
Max.
25
VN1-VNC
ID
mA
VXP1-VXPC
—
7
10
Vth(ON)
Vth(OFF)
OC
Applied between : UP-VUPC, VP-VVPC, WP-VWPC
UN • VN • WN-VNC
1.2
1.7
39
1.5
2.0
53
1.8
2.3
—
V
V
Input OFF Voltage
–20 ≤ Tj ≤ 125°C, VD = 15V
–20 ≤ Tj ≤ 125°C, VD = 15V
VD = 15V
(Fig. 5,6)
Over Current Trip Level
Short Circuit Trip Level
Over Current Delay Time
A
SC
(Fig. 5,6)
(Fig. 5,6)
—
80
—
A
toff(OC)
OT
—
10
—
µs
°C
°C
V
Trip level
100
—
110
90
120
—
Over Temperature protection VD = 15V
OTr
Reset level
Trip level
UV
Supply Circuit Under-Voltage
11.5
—
12.0
12.5
—
12.5
—
–20 ≤ Tj ≤ 125°C
V
UVr
Protection
Reset level
IFO(H)
IFO(L)
—
0.01
15
mA
mA
VD = 15V, VCIN = 15V
VD = 15V
(Note-2)
(Note-2)
Fault Output Current
—
10
Minimum Fault Output Pulse
Width
tFO
1.0
1.8
—
ms
(Note-2) Fault output is given only when the internal SC, OT & UV protections schemes of either upper or lower arm device operate to
protect it.
THERMAL RESISTANCES
Limits
Symbol
Parameter
Test Condition
Unit
Min.
—
Typ.
—
Max.
1.5
Rth(j-c)Q
Rth(j-c)F
Junction to case Thermal
Resistances
Inverter IGBT part (per 1/6 module)
Inverter FWDi part (per 1/6 module)
Case to fin, (per 1 module)
°C/W
°C/W
—
—
3.0
Rth(c-f)
Contact Thermal Resistance
—
—
0.5
°C/W
Thermal grease applied
MECHANICAL RATINGS AND CHARACTERISTICS
Limits
Typ.
1.18
12
Symbol
Parameter
Mounting torque
Weight
Test Condition
—
Unit
Min.
0.98
10
Max.
1.47
15
N • m
kg•cm
g
—
—
Mounting part
screw : M4
—
60
—
RECOMMENDED CONDITIONS FOR USE
Symbol Parameter
Supply Voltage
Test Condition
Recommended value
Unit
V
(Fig. 3)
≤ 400
VCC
Applied across P-N terminals
Applied between : VUP1-VUPC, VVP1-VVPC
VWP1-VWPC, VN1-VNC
15 ± 1.5
VD
Control Supply Voltage
V
(Note-3)
≤ 0.8
≥ 4.0
≤ 15
VCIN(ON)
Input ON Voltage
Applied between : UP-VUPC, VP-VVPC, WP-VWPC
UN • VN • WN-VNC
V
VCIN(OFF) Input OFF Voltage
fPWM
PWM Input Frequency
Arm Shoot-through
Blocking Time
Using Application Circuit of Fig. 8
kHz
µs
tdead
For IPM’s each input signals
(Fig. 7)
≥ 2.5
(Note-3) With ripple satisfying the following conditions
dv/dt swing ≤ ±5V/µs, Variation ≤ 2V peak to peak
