MITSUBISHI MICROCOMPUTERS
3827 Group
SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER
ROM number
GZZ-SH51-93B<85A0>
740 FAMILY ROM PROGRAMMING CONFIRMATION FORM
SINGLE-CHIP MICROCOMPUTER M38279EF-XXXFP/GP/HP
MITSUBISHI ELECTRIC
We recommend the use of the following pseudo-command to set the start address of the assembier source program because
ASCII codes of the product name are written to addresses 000016 to 000816 of EPROM.
EPROM type
27512
*=∆$0000
.BYTE∆ ‘M38279EF-’
The pseudo-command
Note: If the name of the product written to the EPROMs does not match the name of the ROM programming confirmation form,
the ROM will not be processed.
❈ 2. Mark specification
Mark specification must be submitted using the correct form for the package being ordered. Fill out the appropriate mark
specification form (100P6S for M38279EF-XXXFP, 100P6Q for M38279EF-XXXGP, 100PFB for M38279EF-XXXHP) and
attach it to the ROM programming confirmation form.
❈ 3. Usage conditions
Please answer the following questions about usage for use in our product inspection :
(1) How will you use the XIN-XOUT oscillator?
Ceramic resonator
External clock input
Quartz crystal
Other (
)
At what frequency?
f(XIN) =
MHz
MHz
(2) How will you use the XCIN-XCOUT oscillator?
Ceramic resonator
Quartz crystal
Other (
)
At what frequency?
f(XCIN) =
❈ 4. Comments
(2/2)
63
