MITSUBISHI MICROCOMPUTERS
3827 Group
SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER
ROM number
ROM PROGRAMMING CONFIRMATION FORM
GZZ-SH51-93B<85A0>
740 FAMILY ROM PROGRAMMING CONFIRMATION FORM
SINGLE-CHIP MICROCOMPUTER M38279EF-XXXFP/GP/HP
MITSUBISHI ELECTRIC
Date:
Section head Supervisor
signature
signature
Note : Please fill in all items marked ❈.
Submitted by Supervisor
TEL
(
Company
name
)
Customer
❈
Date
issued
Date:
❈ 1. Confirmation
Specify the name of the product being ordered and the type of EPROMs submitted.
Three EPROMs are required for each pattern.
If at least two of the three sets of EPROMs submitted contain identical data, we will produce ROM programming based on
this data. We shall assume the responsibility for errors only if the programming data on the products we produce differs
from this data. Thus, extreme care must be taken to verify the data in the submitted EPROMs.
Product name:
M38279EF-XXXFP
M38279EF-XXXGP
M38279EF-XXXHP
Checksum code for entire EPROM
(hexadecimal notation)
EPROM type (indicate the type used)
27512
In the address space of the microcomputer,
the internal ROM area is from address 108016
to FFFD16. The reset vector is stored in
addresses FFFC16 and FFFD16.
EPROM address
000016
Product name
ASCII code :
‘M38279EF-’
000F16
001016
107F16
108016
Data
ROM 60K-130 bytes
FFFD16
FFFE16
FFFF16
(1) Set the data in the unused area (the shaded area of the
diagram) to “FF16”.
Address
000016
000116
000216
000316
000416
000516
000616
000716
Address
‘M’ = 4D16
000816
000916
000A16
000B16
000C16
000D16
000E16
000F16
‘ – ’ =2D16
FF16
(2) The ASCII codes of the product name “M38279EF-” must
be entered in addresses 000016 to 000816. And set data
“FF16” in addresses 000916 to 000F16. The ASCII codes
and addresses are listed to the right in hesadecimal
notation.
‘3’ = 3316
‘8’ = 3816
‘2’ = 3216
‘7’ = 3716
‘9’ = 3916
‘E’ = 4516
‘F’ = 4616
FF16
FF16
FF16
FF16
FF16
FF16
(1/2)
62
