Preliminary Information
MT9076
Bit
Name
Functional Description
7
FEOL
Framing Bit Error Counter Overflow Latch. This bit is set when the framing bit
counter overflows. It is cleared after being read.
6
5
4
3
2
1
CRCOL
OOFOL
COFAOL
LCVOL
CRC-6 Error Counter Overflow Latch. This bit is set when the crc error counter
overflows. It is cleared after being read.
Out Of Frame Counter Overflow Latch. This bit is set when the out of frame counter
overflows. It is cleared after being read.
Change of Frame Alignment Counter Overflow Latch. This bit is set when the
change of frame alignment counter overflows. It is cleared after being read.
Line Code Violation Counter Overflow Latch. This bit is set when the line code
violation counter overflows. It is cleared after being read.
PRBSOL
Psuedo Random Bit Sequence Error Counter Overflow Latch. This bit is set when
the PRBS error counter overflows. It is cleared after being read.
PRBSMFOL Psuedo Random Bit Sequence Multiframe Counter Overflow Latch. This bit is set
when the multiframe counter attached to the PRBS error counter overflows. It is cleared
after being read
0
MFOOFOL
Multiframes Out Of Sync Overflow Latch. This bit is set when the multiframes out of
sync counter overflows. It is cleared after being read.
Table 78 - Overflow Reporting Latch
(Page 4, Address 1FH) (T1)
87
