PRELIMINARY DATA SHEET
MSP 34x7G
1.3. MSP 34x7G Versions and their Application Fields
Table 1–1 provides an overview of TV sound standards
that can be processed by the MSP 34x7G family. In
addition, the MSP 34x7G is able to handle the FM-
Radio standard. With the MSP 34x7G, a complete
multimedia receiver covering all TV sound standards
together with terrestrial/cable and satellite radio sound
can be built.
Table 1–1: TV Stereo Sound Standards covered by the MSP 34x7G IC Family (details see Appendix A)
MSP Version
TV-
System
Position of Sound
Carrier /MHz
Sound
Modulation
Color
System
Broadcast e.g. in:
5.5/5.7421875
5.5/5.85
FM-Stereo (A2)
PAL
Germany
B/G
FM-Mono/NICAM
AM-Mono/NICAM
FM-Mono/NICAM
FM-Stereo (A2, D/K1)
FM-Stereo (A2, D/K2)
FM-Stereo (A2, D/K3)
PAL
Scandinavia, Spain
France
L
I
6.5/5.85
SECAM-L
PAL
6.0/6.552
UK, Hong Kong
Slovak. Rep.
currently no broadcast
Poland
6.5/6.2578125
6.5/6.7421875
6.5/5.7421875
6.5/5.85
SECAM-East
PAL
D/K
SECAM-East
FM-Mono/NICAM (D/K, NICAM) PAL
China, Hungary
6.5
FM-Mono
7.02/7.2
7.38/7.56
etc.
FM-Stereo
PAL
Europe Sat.
ASTRA
Satellite
4.5/4.724212
FM-Stereo (A2)
FM-FM (EIA-J)
NTSC
Korea
M/N
4.5
NTSC
Japan
4.5
BTSC-Stereo + SAP
FM-Stereo Radio
NTSC, PAL
USA, Argentina
USA, Europe
FM-Radio
10.7
3467
All standards as above, but Mono demodulation only.
33 34 39 MHz
4.5 9 MHz
SAW Filter
Sound
Tuner
IF
Mixer
Loudspeaker
1
Mono
Vision
Demo-
dulator
MSP 34x7G
2
2
SCART
Input
SCART1
SCART1
SCART Output
Composite
Video
Fig. 1–2: Typical MSP 34x7G application
Micronas
7
