PIC18F2480/2580/4480/4580
REGISTER 24-35: BnDLC: TX/RX BUFFER n DATA LENGTH CODE REGISTERS IN TRANSMIT MODE
[0 ≤ n ≤ 5, TXnEN (BSEL<n>) = 1](1)
U-0
—
R/W-x
U-0
—
U-0
—
R/W-x
DLC3
R/W-x
DLC2
R/W-x
DLC1
R/W-x
DLC0
TXRTR
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 7
bit 6
Unimplemented: Read as ‘0’
TXRTR: Transmitter Remote Transmission Request bit
1= Transmitted message will have RTR bit set
0= Transmitted message will have RTR bit cleared
bit 5-4
bit 3-0
Unimplemented: Read as ‘0’
DLC<3:0>: Data Length Code bits
1111-1001= Reserved
1000= Data length = 8 bytes
0111= Data length = 7 bytes
0110= Data length = 6 bytes
0101= Data length = 5 bytes
0100= Data length = 4 bytes
0011= Data length = 3 bytes
0010= Data length = 2 bytes
0001= Data length = 1 bytes
0000= Data length = 0 bytes
Note 1: These registers are available in Mode 1 and 2 only.
REGISTER 24-36: BSEL0: BUFFER SELECT REGISTER 0(1)
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
U-0
—
U-0
—
B5TXEN
B4TXEN
B3TXEN
B2TXEN
B1TXEN
B0TXEN
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 7-2
B5TXEN:B0TXEN: Buffer 5 to Buffer 0 Transmit Enable bit
1= Buffer is configured in Transmit mode
0= Buffer is configured in Receive mode
bit 1-0
Unimplemented: Read as ‘0’
Note 1: These registers are available in Mode 1 and 2 only.
