PIC18F2480/2580/4480/4580
REGISTER 24-23: BnCON: TX/RX BUFFER n CONTROL REGISTERS IN TRANSMIT MODE
[0 ≤ n ≤ 5, TXnEN (BSEL0<n>) = 1](1)
R/W-0
R-0
R-0
R-0
R/W-0
R/W-0
R/W-0
R/W-0
TXBIF(3)
TXABT(3)
TXLARB(3)
TXERR(3) TXREQ(2,4)
RTREN
TXPRI1(5)
TXPRI0(5)
bit 7
bit 0
Legend:
R = Readable bit
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
-n = Value at POR
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1-0
TXBIF: Transmit Buffer Interrupt Flag bit(3)
1= A message is successfully transmitted
0= No message was transmitted
TXABT: Transmission Aborted Status bit(3)
1= Message was aborted
0= Message was not aborted
TXLARB: Transmission Lost Arbitration Status bit(3)
1= Message lost arbitration while being sent
0= Message did not lose arbitration while being sent
TXERR: Transmission Error Detected Status bit(3)
1= A bus error occurred while the message was being sent
0= A bus error did not occur while the message was being sent
TXREQ: Transmit Request Status bit(2,4)
1= Requests sending a message; clears the TXABT, TXLARB and TXERR bits
0= Automatically cleared when the message is successfully sent
RTREN: Automatic Remote Transmission Request Enable bit
1= When a remote transmission request is received, TXREQ will be automatically set
0= When a remote transmission request is received, TXREQ will be unaffected
TXPRI<1:0>: Transmit Priority bits(5)
11= Priority Level 3 (highest priority)
10= Priority Level 2
01= Priority Level 1
00= Priority Level 0 (lowest priority)
Note 1: These registers are available in Mode 1 and 2 only.
2: Clearing this bit in software while the bit is set will request a message abort.
3: This bit is automatically cleared when TXREQ is set.
4: While TXREQ is set or a transmission is in progress, Transmit Buffer registers remain read-only.
5: These bits set the order in which the Transmit Buffer register will be transferred. They do not alter the CAN
message identifier.
