PIC18F2480/2580/4480/4580
REGISTER 24-16: RXBnSIDL: RECEIVE BUFFER n STANDARD IDENTIFIER REGISTERS,
LOW BYTE [0 ≤ n ≤ 1]
R-x
R-x
R-x
R-x
R-x
U-0
—
R-x
R-x
SID2
SID1
SID0
SRR
EXID
EID17
EID16
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 7-5
bit 4
SID<2:0>: Standard Identifier bits (if EXID = 0)
Extended Identifier bits, EID<20:18> (if EXID = 1).
SRR: Substitute Remote Request bit
This bit is always ‘1’ when EXID = 1or equal to the value of RXRTRRO (RBXnCON<3>) when EXID = 0.
EXID: Extended Identifier bit
bit 3
1= Received message is an extended data frame, SID<10:0> are EID<28:18 >
0= Received message is a standard data frame
bit 2
Unimplemented: Read as ‘0’
bit 1-0
EID<17:16>: Extended Identifier bits
REGISTER 24-17: RXBnEIDH: RECEIVE BUFFER n EXTENDED IDENTIFIER REGISTERS,
HIGH BYTE [0 ≤ n ≤ 1]
R-x
R-x
R-x
R-x
R-x
R-x
R-x
R-x
EID15
EID14
EID13
EID12
EID11
EID10
EID9
EID8
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 7-0
EID<15:8>: Extended Identifier bits
REGISTER 24-18: RXBnEIDL: RECEIVE BUFFER n EXTENDED IDENTIFIER REGISTERS,
LOW BYTE [0 ≤ n ≤ 1]
R-x
R-x
R-x
R-x
R-x
R-x
R-x
R-x
EID7
EID6
EID5
EID4
EID3
EID2
EID1
EID0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 7-0
EID<7:0>: Extended Identifier bits
© 2009 Microchip Technology Inc.
DS39637D-page 297
