PIC18CXX2
XORWF
Exclusive OR WREG with f
[ label ] XORWF f,d,a
0 ≤ f ≤ 255
Syntax:
Operands:
d
a
[0,1]
[0,1]
Operation:
(WREG) .XOR. (f) → dest
Status Affected:
Encoding:
N,Z
0001
10da
ffff
ffff
Description:
Exclusive OR the contents of
WREG with register ’f’. If ’d’ is 0, the
result is stored in WREG. If ’d’ is 1,
the result is stored back in the reg-
ister 'f' (default). If ’a’ is 0, the
Access Bank will be selected, over-
riding the BSR value. If ’a’ is 1,
then the bank will be selected as
per the BSR value (default).
Words:
Cycles:
1
1
Q Cycle Activity:
Q1
Q2
Q3
Q4
Decode
Read
register ’f’
Process
Data
Write to
destination
Example:
XORWF REG, 1, 0
Before Instruction
REG
WREG
=
=
0xAF
0xB5
After Instruction
REG
WREG
=
=
0x1A
0xB5
DS39026B-page 234
Preliminary
7/99 Microchip Technology Inc.
