PIC18F6525/6621/8525/8621
Once the given operation is complete (i.e., transmis-
sion of the last data bit is followed by ACK), the internal
clock will automatically stop counting and the SCL pin
will remain in its last state.
18.4.7
BAUD RATE GENERATOR
In I2C Master mode, the Baud Rate Generator (BRG)
reload value is placed in the lower 7 bits of the
SSPADD register (Figure 18-17). When a write occurs
to SSPBUF, the Baud Rate Generator will automatically
begin counting. The BRG counts down to ‘0’ and stops
until another reload has taken place. The BRG count is
decremented twice per instruction cycle (TCY) on the
Q2 and Q4 clocks. In I2C Master mode, the BRG is
reloaded automatically.
Table 18-3 demonstrates clock rates based on
instruction cycles and the BRG value loaded into
SSPADD.
FIGURE 18-17:
BAUD RATE GENERATOR BLOCK DIAGRAM
SSPM3:SSPM0
SSPADD<6:0>
SSPM3:SSPM0
SCL
Reload
Control
Reload
BRG Down Counter
CLKO
FOSC/4
TABLE 18-3: I2C™ CLOCK RATE w/BRG
FSCL
FOSC
FCY
FCY*2
BRG Value
(2 Rollovers of BRG)
40 MHz
40 MHz
40 MHz
16 MHz
16 MHz
16 MHz
4 MHz
10 MHz
10 MHz
10 MHz
4 MHz
4 MHz
4 MHz
1 MHz
1 MHz
1 MHz
20 MHz
20 MHz
20 MHz
8 MHz
8 MHz
8 MHz
2 MHz
2 MHz
2 MHz
18h
1Fh
63h
09h
0Ch
27h
02h
09h
00h
400 kHz(1)
312.5 kHz
100 kHz
400 kHz(1)
308 kHz
100 kHz
333 kHz(1)
4 MHz
100 kHz
1 MHz(1)
4 MHz
Note 1: The I2C interface does not conform to the 400 kHz I2C specification (which applies to rates greater than
100 kHz) in all details, but may be used with care where higher rates are required by the application.
2005 Microchip Technology Inc.
DS39612B-page 199
