PIC17C75X
When an interrupt is responded to, the GLINTD bit is
automatically set to disable any further interrupts, the
return address is pushed onto the stack and the PC is
loaded with the interrupt vector address.There are four
interrupt vectors. Each vector address is for a specific
interrupt source (except the peripheral interrupts which
all vector to the same address). These sources are:
6.0
INTERRUPTS
The PIC17C75X devices have 18 sources of interrupt:
• External interrupt from the RA0/INT pin
• Change on RB7:RB0 pins
• TMR0 Overflow
• TMR1 Overflow
• TMR2 Overflow
• TMR3 Overflow
• External interrupt from the RA0/INT pin
• TMR0 Overflow
• T0CKI edge occurred
• USART1 Transmit buffer empty
• USART1 Receive buffer full
• USART2 Transmit buffer empty
• USART2 Receive buffer full
• SSP Interrupt
• Any peripheral interrupt
When program execution vectors to one of these inter-
rupt vector addresses (except for the peripheral inter-
rupts), the interrupt flag bit is automatically cleared.
Vectoring to the peripheral interrupt vector address
does not automatically clear the source of the interrupt.
In the peripheral interrupt service routine, the source(s)
of the interrupt can be determined by testing the inter-
rupt flag bits.The interrupt flag bit(s) must be cleared in
software before re-enabling interrupts to avoid infinite
interrupt requests.
2
• SSP I C bus collision interrupt
• A/D conversion complete
• Capture1
• Capture2
• Capture3
• Capture4
• T0CKI edge occurred
There are six registers used in the control and status of
interrupts. These are:
When an interrupt condition is met, that individual inter-
rupt flag bit will be set regardless of the status of its cor-
responding mask bit or the GLINTD bit.
• CPUSTA
• INTSTA
• PIE1
• PIR1
• PIE2
For external interrupt events, there will be an interrupt
latency. For two cycle instructions, the latency could be
one instruction cycle longer.
• PIR2
The “return from interrupt” instruction, RETFIE, can be
used to mark the end of the interrupt service routine.
When this instruction is executed, the stack is
“POPed”, and the GLINTD bit is cleared (to re-enable
interrupts).
The CPUSTA register contains the GLINTD bit. This is
the Global Interrupt Disable bit. When this bit is set, all
interrupts are disabled. This bit is part of the controller
core functionality and is described in the Memory Orga-
nization section.
FIGURE 6-1: INTERRUPT LOGIC
RBIF
RBIE
TMR3IF
TMR3IE
TMR2IF
TMR2IE
TMR1IF
TMR1IE
INTSTA
Wake-up (If in SLEEP mode)
or terminate long write
CA2IF
CA2IE
T0IF
T0IE
CA1IF
CA1IE
TX1IF
TX1IE
INTF
INTE
Interrupt to CPU
T0CKIF
RC1IF
RC1IE
T0CKIE
PEIF
SSPIF
SSPIE
PEIE
BCLIF
BCLIE
GLINTD (CPUSTA<4>)
ADIF
ADIE
CA4IF
CA4IE
CA3IF
CA3IE
TX2IF
TX2IE
RC2IF
RC2IE
1997 Microchip Technology Inc.
Preliminary
DS30264A-page 29
