PIC16F913/914/916/917/946
19.1 DC Characteristics: PIC16F913/914/916/917/946-I (Industrial)
PIC16F913/914/916/917/946-E (Extended)
Standard Operating Conditions (unless otherwise stated)
Operating temperature -40°C ≤ TA ≤ +85°C for industrial
-40°C ≤ TA ≤ +125°C for extended
DC CHARACTERISTICS
Param
Sym.
Characteristic
Min. Typ† Max. Units
Conditions
No.
VDD
Supply Voltage
2.0
2.0
3.0
4.5
—
—
—
—
5.5
5.5
5.5
5.5
V
V
V
V
FOSC < = 8 MHz: HFINTOSC, EC
FOSC < = 4 MHz
FOSC < = 10 MHz
D001
D001C
D001D
FOSC < = 20 MHz
D002* VDR
RAM Data Retention
Voltage(1)
1.5
—
—
V
Device in Sleep mode
D003 VPOR
VDD Start Voltage to
ensure internal Power-on
Reset signal
—
VSS
—
V
See Section 16.2.1 “Power-on Reset
(POR)” for details.
D004* SVDD
VDD Rise Rate to ensure
internal Power-on Reset
signal
0.05
—
—
V/ms See Section 16.2.1 “Power-on Reset
(POR)” for details.
*
These parameters are characterized but not tested.
†
Data in “Typ” column is at 5.0V, 25°C unless otherwise stated. These parameters are for design guidance
only and are not tested.
Note 1: This is the limit to which VDD can be lowered in Sleep mode without losing RAM data.
© 2007 Microchip Technology Inc.
DS41250F-page 257
