PIC16C745/765
2.3
Quick-Turnaround-Production (QTP)
Devices
2.0
PIC16C745/765 DEVICE
VARIETIES
A variety of frequency ranges and packaging options
are available. Depending on application and production
requirements, the proper device option can be selected
using the information in the PIC16C745/765 Product
Identification System section at the end of this data
sheet. When placing orders, please use that page of
the data sheet to specify the correct part number.
Microchip offers a QTP Programming Service for fac-
tory production orders. This service is made available
for users who choose not to program a medium to high
quantity of units and whose code patterns have stabi-
lized. The devices are identical to the OTP devices but
with all EPROM locations and configuration options
already programmed by the factory. Certain code and
prototype verification procedures apply before produc-
tion shipments are available. Please contact your local
Microchip Technology sales office for more details.
2.1
UV Erasable Devices
The UV erasable version, offered in windowed CERDIP
packages (600 mil), is optimal for prototype develop-
ment and pilot programs. This version can be erased
and reprogrammed to any of the supported oscillator
modes.
2.4
Serialized Quick-Turnaround
Production (SQTPSM) Devices
Microchip offers a unique programming service where
a few user-defined locations in each device are pro-
grammed with different serial numbers. The serial num-
bers may be random, pseudo-random or sequential.
Microchip’s PICSTART
Plus and PRO MATE II
programmers both support programming of the
PIC16C745/765.
Serial programming allows each device to have a
unique number, which can serve as an entry-code,
password or ID number.
2.2
One-Time-Programmable (OTP)
Devices
The availability of OTP devices is especially useful for
customers who need the flexibility for frequent code
updates and small volume applications.
The OTP devices, packaged in plastic packages, per-
mit the user to program them once. In addition to the
program memory, the configuration bits must also be
programmed.
1999 Microchip Technology Inc.
Advanced Information
DS41124A-page 7
