PIC16C55X(A)
4.2.2.4
PCON REGISTER
The PCON register contains flag bits to differentiate
between a Power-on Reset, an external MCLR reset or
WDT reset. See Section 7.3 and Section 7.4 for
detailed reset operation.
FIGURE 4-9: PCON REGISTER (ADDRESS 8Eh)
U-0
—
U-0
—
U-0
—
U-0
—
U-0
—
U-0
—
R/W-0
POR
U-0
—
R
= Readable bit
W = Writable bit
bit7
bit0
U
= Unimplemented bit,
read as ‘0’
- n = Value at POR reset
bit 7-2: Unimplemented: Read as '0'
bit 1:
POR: Power-on Reset Status bit
1 = No Power-on Reset occurred
0 = Power-on Reset occurred
bit 0:
Unimplemented: Read as '0'
DS40143B-page 20
Preliminary
1997 Microchip Technology Inc.
