PIC16C55X(A)
4.2.2.3
INTCON REGISTER
Note: Interrupt flag bits get set when an interrupt
condition occurs regardless of the state of
its corresponding enable bit or the global
enable bit, GIE (INTCON<7>).
The INTCON register is a readable and writable
register which contains the various enable and flag bits
for all interrupt sources.
FIGURE 4-8: INTCON REGISTER (ADDRESS 0BH OR 8BH)
R/W-0 Reserved R/W-0
GIE T0IE
bit7
R/W-0
INTE
R/W-0
RBIE
R/W-0
T0IF
R/W-0
INTF
R/W-x
RBIF
—
R = Readable bit
W = Writable bit
- n = Value at POR reset
- x = Unknown at POR reset
bit0
bit 7:
GIE: Global Interrupt Enable bit
1 = Enables all un-masked interrupts
0 = Disables all interrupts
bit 6:
bit 5:
— = Reserved for future use. Always maintain this bit clear.
T0IE: TMR0 Overflow Interrupt Enable bit
1 = Enables the TMR0 interrupt
0 = Disables the TMR0 interrupt
bit 4:
bit 3:
bit 2:
bit 1:
bit 0:
INTE: RB0/INT External Interrupt Enable bit
1 = Enables the RB0/INT external interrupt
0 = Disables the RB0/INT external interrupt
RBIE: RB Port Change Interrupt Enable bit
1 = Enables the RB port change interrupt
0 = Disables the RB port change interrupt
T0IF: TMR0 Overflow Interrupt Flag bit
1 = TMR0 register has overflowed (must be cleared in software)
0 = TMR0 register did not overflow
INTF: RB0/INT External Interrupt Flag bit
1 = The RB0/INT external interrupt occurred (must be cleared in software)
0 = The RB0/INT external interrupt did not occur
RBIF: RB Port Change Interrupt Flag bit
1 = When at least one of the RB7:RB4 pins changed state (must be cleared in software)
0 = None of the RB7:RB4 pins have changed state
