PIC16C63A/65B/73B/74B
COMF
Complement f
GOTO
Unconditional Branch
[ label ] GOTO k
0 ≤ k ≤ 2047
Syntax:
Operands:
[ label ] COMF f,d
Syntax:
0 ≤ f ≤ 127
d ∈ [0,1]
Operands:
Operation:
k → PC<10:0>
PCLATH<4:3> → PC<12:11>
Operation:
(f) → (destination)
Status Affected:
Description:
Z
Status Affected: None
The contents of register ’f’ are comple-
mented. If ’d’ is 0, the result is stored
in W. If ’d’ is 1, the result is stored
back in register ’f’.
GOTOis an unconditional branch. The
Description:
eleven bit immediate value is loaded
into PC bits <10:0>. The upper bits of
PC are loaded from PCLATH<4:3>.
GOTOis a two-cycle instruction.
DECF
Decrement f
INCF
Increment f
Syntax:
Operands:
[label] DECF f,d
Syntax:
Operands:
[ label ] INCF f,d
0 ≤ f ≤ 127
d ∈ [0,1]
0 ≤ f ≤ 127
d ∈ [0,1]
Operation:
(f) - 1 → (destination)
Operation:
(f) + 1 → (destination)
Status Affected:
Description:
Z
Status Affected:
Description:
Z
Decrement register ’f’. If ’d’ is 0, the
result is stored in the W register. If ’d’
is 1, the result is stored back in
register ’f’.
The contents of register ’f’ are incre-
mented. If ’d’ is 0, the result is placed
in the W register. If ’d’ is 1, the result is
placed back in register ’f’.
DECFSZ
Syntax:
Decrement f, Skip if 0
INCFSZ
Syntax:
Increment f, Skip if 0
[ label ] DECFSZ f,d
[ label ] INCFSZ f,d
Operands:
0 ≤ f ≤ 127
d ∈ [0,1]
Operands:
0 ≤ f ≤ 127
d ∈ [0,1]
Operation:
(f) - 1 → (destination);
skip if result = 0
Operation:
(f) + 1 → (destination),
skip if result = 0
Status Affected: None
Status Affected: None
The contents of register ’f’ are decre-
The contents of register ’f’ are incre-
Description:
Description:
mented. If ’d’ is 0, the result is placed
in the W register. If ’d’ is 1, the result is
placed back in register ’f’.
mented. If ’d’ is 0, the result is placed
in the W register. If ’d’ is 1, the result is
placed back in register ’f’.
If the result is 1, the next instruction is
executed. If the result is 0, then a NOP
is executed instead making it a 2 TCY
instruction.
If the result is 1, the next instruction is
executed. If the result is 0, a NOPis
executed instead making it a 2 TCY
instruction.
2000 Microchip Technology Inc.
DS30605C-page 103
