PIC12F683
REGISTER 9-1:
ADCON0 – A/D CONTROL REGISTER (ADDRESS: 1Fh)
R/W-0
ADFM
R/W-0
VCFG
U-0
—
R/W-0
—
R/W-0
CHS1
R/W-0
CHS0
R/W-0
R/W-0
ADON
GO/DONE
bit 7
bit 0
bit 7
bit 6
ADFM: A/D Result Formed Select bit
1= Right justified
0= Left justified
VCFG: Voltage Reference bit
1= VREF pin
0= VDD
bit 5-4
bit 3-2
Unimplemented: Read as ‘0’
CHS<1:0>: Analog Channel Select bits
00= Channel 00 (AN0)
01= Channel 01 (AN1)
10= Channel 02 (AN2)
11= Channel 03 (AN3)
bit 1
bit 0
GO/DONE: A/D Conversion Status bit
1= A/D conversion cycle in progress. Setting this bit starts an A/D conversion cycle.
This bit is automatically cleared by hardware when the A/D conversion has completed.
0= A/D conversion completed/not in progress
ADON: A/D Conversion Status bit
1= A/D converter module is operating
0= A/D converter is shut off and consumes no operating current
Legend:
R = Readable bit
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
- n = Value at POR
DS41211B-page 58
Preliminary
2004 Microchip Technology Inc.
