PIC12(L)F1501
30.0 PACKAGING INFORMATION
30.1 Package Marking Information
8-Lead PDIP (300 mil)
Example
12F1501
XXXXXXXX
XXXXXNNN
e
3
I/P
017
YYWW
1110
8-Lead SOIC (3.90 mm)
Example
12F1501
I/SN1110
017
NNN
Legend: XX...X Customer-specific information
Y
YY
WW
NNN
Year code (last digit of calendar year)
Year code (last 2 digits of calendar year)
Week code (week of January 1 is week ‘01’)
Alphanumeric traceability code
e
3
Pb-free JEDEC designator for Matte Tin (Sn)
*
This package is Pb-free. The Pb-free JEDEC designator (
can be found on the outer packaging for this package.
)
e3
Note: In the event the full Microchip part number cannot be marked on one line, it will
be carried over to the next line, thus limiting the number of available
characters for customer-specific information.
*
Standard PICmicro® device marking consists of Microchip part number, year code, week code and
traceability code. For PICmicro device marking beyond this, certain price adders apply. Please check
with your Microchip Sales Office. For QTP devices, any special marking adders are included in QTP
price.
2011 Microchip Technology Inc.
Preliminary
DS41615A-page 253
