24AA02/24LC02B
1st Line Marking Codes
SOT-23
Part Number
DFN
TSSOP
MSOP
I Temp.
E Temp.
I Temp.
E Temp.
24AA02
4A02
4L02
4A02T
4L2BT
B2NN
M2NN
—
221
224
—
24LC02B
N2NN
225
Note:
T = Temperature grade (I, E)
NN = Alphanumeric traceability code
Legend: XX...X Part number or part number code
T
Temperature (I, E)
Y
Year code (last digit of calendar year)
YY
WW
NNN
Year code (last 2 digits of calendar year)
Week code (week of January 1 is week ‘01’)
Alphanumeric traceability code (2 characters for small packages)
Pb-free JEDEC designator for Matte Tin (Sn)
e
3
Note:
For very small packages with no room for the Pb-free JEDEC designator
, the marking will only appear on the outer carton or reel label.
e
3
Note: In the event the full Microchip part number cannot be marked on one line, it will
be carried over to the next line, thus limiting the number of available
characters for customer-specific information.
Note:
Please visit www.microchip.com/Pbfree for the latest information on Pb-free conversion.
*Standard OTP marking consists of Microchip part number, year code, week code, and traceability code.
© 2007 Microchip Technology Inc.
DS21709G-page 13
