KSZ8795CLX
TABLE 4-27: FORMAT OF PER-PORT MIB COUNTER
Address
Name
Description
Mode
Default
For Port 2, the base is 0x20, same offset definition (0x20-0x3f)
For Port 3, the base is 0x40, same offset definition (0x40-0x5f)
For Port 4, the base is 0x60, same offset definition (0x60-0x7f)
For Port 5, the base is 0x80, same offset definition (0x80-0x9f)
38
Overflow
1 = Counter overflow.
0 = No Counter overflow.
RO
RO
0
0
37
Count Valid 1 = Counter value is valid.
0 = Counter value is not valid.
36 - 30
29 - 0
Reserved
—
RO
RO
All ‘0’
0
Counter
Values
Counter Value
TABLE 4-28: ALL PORT DROPPED PACKET MIB COUNTERS
Offset
Counter Name
Description
Port 1 Rx total octet count, including bad packets.
0x100
0x101
0x102
0x103
0x104
0x105
0x106
0x107
0x108
0x109
0x10A
0x10B
0x10C
0x10D
0x10E
0x10F
0x110
0x111
0x112
0x113
Port 1 Rx Total Bytes
Port 1 Tx Total Bytes
Port 1 Rx Drop Packets
Port 1 Tx Drop Packets
Port 2 Rx Total Bytes
Port 2 Tx Total Bytes
Port 2 Rx Drop Packets
Port 2 Tx Drop Packets
Port 3 Rx Total Bytes
Port 3 Tx Total Bytes
Port 3 Rx Drop Packets
Port 3 Tx Drop Packets
Port 4 Rx Total Bytes
Port 4 Tx Total Bytes
Port 4 Rx Drop Packets
Port 4 Tx Drop Packets
Port 5 Rx Total Bytes
Port 5 Tx Total Bytes
Port 5 Rx Drop Packets
Port 5 Tx Drop Packets
Port 1 Tx total good octet count, including PAUSE packets.
Port 1 Rx packets dropped due to lack of resources.
Port 1 Tx packets dropped due to lack of resources.
Port 2 Rx total octet count, including bad packets.
Port 2 Tx total good octet count, including PAUSE packets.
Port 2 Rx packets dropped due to lack of resources.
Port 2 Tx packets dropped due to lack of resources.
Port 3 Rx total octet count, including bad packets.
Port 3 Tx total good octet count, including PAUSE packets.
Port 3 Rx packets dropped due to lack of resources.
Port 3 Tx packets dropped due to lack of resources.
Port 4 Rx total octet count, including bad packets.
Port 4 Tx total good octet count, including PAUSE packets.
Port 4 Rx packets dropped due to lack of resources.
Port 4 Tx packets dropped due to lack of resources.
Port 5 Rx total octet count, including bad packets.
Port 5 Tx total good octet count, including PAUSE packets.
Port 5 Rx packets dropped due to lack of resources.
Port 5 Tx packets dropped due to lack of resources.
TABLE 4-29: FORMAT OF PER-PORT RX/TX TOTAL BYTES MIB COUNTER (IN TABLE 4-28)
Address
Name
Description
Mode
Default
38
Overflow
1 = Counter overflow.
RO
0
0 = No Counter overflow.
37
Count Valid 1 = Counter value is valid.
0 = Counter value is not valid.
RO
0
36
Reserved
—
RO
RO
0
0
35 - 0
Counter
Values
Counter value
DS00002112A-page 106
2016 Microchip Technology Inc.
