TABLE 4-26: PORT MIB COUNTER INDIRECT MEMORY OFFSETS (CONTINUED)
Offset
Counter Name
Description
0x8
RxControl8808Pkts
The number of MAC control frames received by a port with 88-08h in
EtherType field.
0x9
RxPausePkts
The number of PAUSE frames received by a port. PAUSE frame is
qualified with EtherType (88-08h), DA, control opcode (00-01), data
length (64 byte min), and a valid CRC.
0xA
0xB
RxBroadcast
RxMulticast
Rx good broadcast packets (not including errored broadcast packets or
valid multicast packets).
Rx good multicast packets (not including MAC control frames, errored
multicast packets or valid broadcast packets).
0xC
0xD
0xE
RxUnicast
Rx good unicast packets.
Rx64Octets
Total Rx packets (bad packets included) that were 64 octets in length.
Rx65to127Octets
Total Rx packets (bad packets included) that are between 65 and 127
octets in length.
0xF
Rx128to255Octets
Rx256to511Octets
Rx512to1023Octets
Rx1024to1522Octets
Rx1523to2000Octets
Rx2001toMax-1Octets
Total Rx packets (bad packets included) that are between 128 and 255
octets in length.
0x10
0x11
0x12
0x13
0x14
Total Rx packets (bad packets included) that are between 256 and 511
octets in length.
Total Rx packets (bad packets included) that are between 512 and
1023 octets in length.
Total Rx packets (bad packets included) that are between 1024 and
1522 octets in length.
Total Rx packets (bad packets included) that are between 1523 and
2000 octets in length.
Total Rx packets (bad packets included) that are between 2001 and
Max-1 octets in length (upper limit depends on max packet size ?1).
0x15
0x16
TxHiPriorityByte
TxLateCollision
Tx hi-priority good octet count, including PAUSE packets.
The number of times a collision is detected later than 512 bit-times into
the Tx of a packet.
0x17
0x18
TxPausePkts
The number of PAUSE frames transmitted by a port.
TxBroadcastPkts
Tx good broadcast packets (not including errored broadcast or valid
multicast packets).
0x19
TxMulticastPkts
Tx good multicast packets (not including errored multicast packets or
valid broadcast packets).
0x1A
0x1B
TxUnicastPkts
TxDeferred
Tx good unicast packets.
Tx packets by a port for which the 1st Tx attempt is delayed due to the
busy medium.
0x1C
0x1D
0x1E
TxTotalCollision
Tx total collision, half-duplex only.
TxExcessiveCollision
TxSingleCollision
A count of frames for which Tx fails due to excessive collisions.
Successful Tx frames on a port for which Tx is inhibited by exactly one
collision.
0x1F
TxMultipleCollision
Successful Tx frames on a port for which Tx is inhibited by more than
one collision.
