MX29LV800T/B
ERASE AND PROGRAMMING PERFORMANCE(1)
LIMITS
PARAMETER
MIN.
TYP.(2)
MAX.(3)
UNITS
Sector Erase Time
0.7
14
9
15
sec
sec
Chip Erase Time
Byte Programming Time
Word Programming Time
Chip Programming Time
300
360
27
us
11
9
us
Byte Mode
Word Mode
sec
5.8
17
sec
Erase/Program Cycles
100,000
Cycles
Note: 1.Not 100% Tested, Excludes external system level over head.
2.Typical values measured at 25°C, 3V.
3.Maximum values measured at 25°C, 2.7V.
LATCHUP CHARACTERISTICS
MIN.
-1.0V
MAX.
Input Voltage with respect to GND on all pins except I/O pins
Input Voltage with respect to GND on all I/O pins
Current
12.5V
Vcc + 1.0V
+100mA
-1.0V
-100mA
Includes all pins except Vcc. Test conditions: Vcc = 3.0V, one pin at a time.
P/N:PM0709
REV. 1.3, JAN. 24, 2002
