MX29LA129M H/L
AC CHARACTERISTICS
Parameter Description
Test Setup All Speed Options Unit
tREADY1
RESET# PIN Low (During Automatic Algorithms)
MAX
20
us
to Read or Write (See Note)
tREADY2
RESET# PIN Low (NOT During Automatic Algorithms)
to Read or Write (See Note)
MAX
500
ns
tRP
RESET# Pulse Width (NOT During Automatic Algorithms)
RESET# HighTime Before Read (See Note)
RY/BY# Recovery Time(to CEx, OE# go low)
RESET# Low to Standby Mode
MIN
MIN
MIN
MIN
500
50
0
ns
ns
ns
us
tRH
tRB
tRPD
20
Note:Not 100% tested
Figure 3. RESET# TIMING WAVEFORM
RY/BY#
CEx, OE#
tRH
RESET#
tRP
tReady2
Reset Timing NOT during Automatic Algorithms
tReady1
RY/BY#
tRB
CEx, OE#
RESET#
tRP
Reset Timing during Automatic Algorithms
P/N:PM1171
REV. 1.0, FEB. 27, 2006
38
