MX29LA129M H/L
OPERATING RATINGS
ABSOLUTE MAXIMUM RATINGS
StorageTemperature
Commercial (C) Devices
Plastic Packages . . . . . . . . . . . . . ..... -65oC to +150oC
Ambient Temperature (TA ). . . . . . . . . . . . 0°C to +70°C
Industrial (I) Devices
AmbientTemperature
with Power Applied. . . . . . . . . . . . . .... -65oC to +125oC
Voltage with Respect to Ground
Ambient Temperature (TA ). . . . . . . . . . -40°C to +85° C
VCC Supply Voltages
VCC for full voltage range. . . . . . . . . . . +2.7 V to 3.6 V
VCC for regulated voltage range. . . . . .. +3.0 V to 3.6 V
VCC (Note 1) . . . . . . . . . . . . . . . . . -0.5 V to +4.0 V
A10, OE#, and
RESET# (Note 2) . . . . . . . . . . . ....-0.5 V to +12.5 V
All other pins (Note 1) . . . . . . . -0.5 V to VCC +0.5 V
Output Short Circuit Current (Note 3) . . . . . . 200 mA
Operating ranges define those limits between which the
functionality of the device is guaranteed.
Notes:
1. Minimum DC voltage on input or I/O pins is -0.5 V.
During voltage transitions, input or I/O pins may over-
shoot VSS to -2.0 V for periods of up to 20 ns. Maxi-
mum DC voltage on input or I/O pins is VCC +0.5 V.
During voltage transitions, input or I/O pins may over-
shoot to VCC +2.0 V for periods up to 20ns.
2. Minimum DC input voltage on pins A10, OE#, and
RESET# is -0.5 V. During voltage transitions, A10,
OE#, and RESET# may overshoot VSS to -2.0 V for
periods of up to 20 ns. Maximum DC input voltage on
pin A10 is +12.5 V which may overshoot to 14.0 V for
periods up to 20 ns.
3.No more than one output may be shorted to ground at
a time. Duration of the short circuit should not be
greater than one second.
Stresses above those listed under "Absolute Maximum
Ratings" may cause permanent damage to the device.
This is a stress rating only; functional operation of the
device at these or any other conditions above those in-
dicated in the operational sections of this data sheet is
not implied. Exposure of the device to absolute maxi-
mum rating conditions for extended periods may affect
device reliability.
P/N:PM1171
REV. 1.0, FEB. 27, 2006
33
