MCC
Micro Commercial Components
TM
20736 Marilla
Street Chatsworth

  !"#
$%    !"#
BAS16
Features
Low Current Leakage
Low Cost
Small Outline Surface Mount Package
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Marking :A6
Halogen
free available upon request by adding suffix "-HF"
Lead Free Finish/Rohs Compliant ("P"Suffix designates
RoHS Compliant. See ordering information)
350mW 100Volt
Switching Diode
SOT-23
A
D
Maximum Ratings
Operating Temperature: -55°C to +150°C
Storage Temperature: -55°C to +150°C
Maximum Thermal Resistance; 357K/W Junction To Ambient
F
E
C
B
G
H
J
Electrical Characteristics @ 25°C Unless Otherwise Specified
Reverse Voltage
Peak Reverse
Voltage
Peak Forward
Current
Power Dissipation
Peak Forward Surge
Current
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current At
Rated DC Blocking
Voltage
Typical Junction
Capacitance
Reverse Recovery
Time
V
R
V
RM
I
F
P
TOT
I
FSM
V
F
75V
100V
300mA
350mW
1A
DIM
A
B
C
D
E
F
G
H
J
K
INCHES
MIN
.110
.083
.047
.035
.070
.018
.0005
.035
.003
.015
DIMENSIONS
MM
MIN
2.80
2.10
1.20
.89
1.78
.45
.013
.89
.085
.37
t=1s, None Repet.
1.25V
I
R
1µA
50µA
2pF
I
FM
= 150mA;
T
J
= 25°C*
V
R
=75Volts
T
J
= 25°C
T
J
= 150°C
MAX
.120
.098
.055
.041
.081
.024
.0039
.044
.007
.020
MAX
3.04
2.64
1.40
1.03
2.05
.60
.100
1.12
.180
.51
NOTE
Suggested Solder
Pad Layout
.031
.800
.035
.900
.079
2.000
inches
mm
Measured at
1.0MHz, V
R
=0V
T
rr
4ns
I
F
=10mA
V
R
= 6.0V
R
L
=100Ω
*Pulse test: Pulse width 300
µsec,
Duty cycle 2%
C
J
.037
.950
.037
.950
Revision:
B
www.mccsemi.com
1 of 3
2013/01/01
