ENVIRONMENTAL SPECIFICATIONS
PHYSICAL CHARACTERISTICS
Min Typ Max Unit/Comments
Unit/Comments
o
-40
-40
+75 C; Ambient
Operating Temp. Range
Storage Temp. Range
Relative Humidity
Case Size
2.0 X 2.0 X 0.4 inches
(51.0 X 51.0 X 10.2 mm)
Painted Metal with Non-
Conductive Base
Output Common Pin
UL94V-0
o
+125 C
+95 % Humidity; non-
condensing
Case Material
Free-Air Convection
Cooling
Shield Connection
Flammability
Weight
74 Grams
OUTLINE DRAWING
2.00 (50.8)
0.40
(10.2)
0.60
(15.2)
0.40
(10.2)
0.040 .005
(1.01) DIA.
ꢀ
4
5
+Vout COM -Vout
2.00
(50.8)
0.80
(20.ꢀ)
BOTTOM
SIDE
+Vin -Vin
1
2
0.60
(15.2)
0.22 MIN.
(5.6)
0.20
(5.1)
0.90
(22.9)
0.40
(10.2)
PIN OUT CHART
Pins
Dual
+ Vin
Notes:
1. Unless otherwise specified dimensions are in inches (mm).
1
2
ꢀ
4
5
- Vin
Tolerances
Inches
X.XX = 0.02
X.XXX= 0.010
mm
X.X = 0.5
X.XX = 0.25
+ Vout
Common
- Vout
NC = No Connection
All specifications are typical at nominal input, nominal load and 25° C unless otherwise specified.
External, low ESR, 10 microfarad (minimum) capacitor across output is recommended for operation.
