Note: All part numbers
are RoHS Compliant.
AMP Circular Connectors for
Commercial Signal and Power Applications
Sealed Circular Plastic Connectors
Multimate Size 16 Contacts
Precision formed signal/low current
Pin Diameter—.062 [1.57]
Test Current—13 amps max.
.125 POWERBAND Contacts
Precision formed high current
Pin Diameter—.125 [3.175]
Test Current—50 amps max.
Type III+
Precision Formed Contacts
Type II
Screw-Machined Contacts
Extraction Tool
Part Number 318813-1
(Instruction Sheet 408-4374)
See pages 17-23 for complete product information and part numbers of Size 16
contacts applicable in Sealed CPC Connectors.
.125
[3.18]
Dia.
.206
[5.23]
Serrations
Dia.
Material and Finish
Contacts—Copper with beryllium
copper spring
Plating Code
A — Post plated .000200 [0.00508]
min. silver in mating area with .000050
[0.00127] min. silver on remainder of
contact, all over .000050 [0.00127] min.
nickel
B — Post plated .000030 [0.00076]
min. gold in mating area with gold flash
on remainder of contact, all over
.000050 [0.00127] min. nickel
Contact
Strip
Extended1
.485
[12.32]
.206
[5.23]
Dia.
Standard
.400
[10.16]
Related Product Data
Application Tooling—Pages 76-79
Technical Documents—Page 80
.125 POWERBAND
Pin Contact
.125 POWERBAND
Socket Contact
Tooling Part No.
Contact Part No.
Heavy Duty Miniature (HDM)
Die Sets for
Wire Size
AWG/mm2
Contact
Finish
Pin
Length
Strip
Socket
Loose Piece
Pin Socket
Applicators (for AMP-O-LECTRIC Hand Tool 69710-1
Model G Machine,
Base Part No. 354500)
or 626 Pneumatic Tool
System*
Pin
A
B
A
B
A
B
A
B
Standard
Standard
Extended1
Extended1
Standard
Standard
Extended1
Extended1
213845-1 213847-1
213845-2 213847-2
213845-3 213847-3
213845-4 213847-4
14-12
680195-3
680197-3
356612-1
2-3
213845-5
213845-6
—
—
213845-7
213845-8
—
—
213841-1 213843-1
213841-2 213843-2
213841-3 213843-3
213841-4 213843-4
356611-1 (8 AWG)
356611-2 (10 AWG)
10-8
5-8
213841-5
213841-6
—
—
213841-7
213841-8
—
—
1For use in One-Piece or Two-Piece Sealed Circular Plastic Connectors (CPC), Series 5 and 6.
‡Single contact, free-air test current; not to be construed as contact rating current. Use only for testing.
Refer to contact current carrying capability information, page 8.
Note: Standard Size 8, High Current Upgrade Size 8, and .125 POWERBAND contacts are not intermateable.
*A typical 626 Pneumatic Tool System requires: a power unit (Part No. 189721-2, hand actuated or 189722-2, foot actuated), an adapter
holder (Part No. 356304-1, with ratchet), and “C” Head adapter Part No. 318161-1.
Specifically designed for
AMP CPC Connectors,
Series 5 and 6, the new
.125 POWERBAND contact
offers the performance of a
MIL-Spec screw machined
Size 8 contact with the
economy of a stamped
and formed, strip-feed
contact. Strip-feed contacts
offer maximum production
capabilities using standard
AMP bench-mount, semi-
automatic termination
prototype or maintenance
and repair requirements,
the .125 POWERBAND
contact is available in loose
piece form.
equipment. For low volume,
47
Catalog 82021
Revised 7-07
Dimensions are in inches and
Dimensions are shown for
USA: 1-800-522-6752
South America: 55-11-2103-6000
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
millimeters unless otherwise
reference purposes only.
Specifications subject
to change.
Canada: 1-905-470-4425
Mexico: 52-55-1106-0800
C. America: 57-1-254-4444
specified. Values in brackets
are metric equivalents.
