RF Coax Connectors
BNC Connectors, 50 Ohm (Continued)
Jacks, Twist-On
Related Product Data
Twist-on jacks must be used with
cable that has a solid conductor.
These jacks are not recommended
for applications where the cable
frequently moves or flexes.
40.14
[1.580]
Max.
Mating Twist-On Plug—Page 50
RG/U
Cable
Center
Body
Dielectric
Style
Part No.
222428-1
Contact
Plating
59, 59A, 59B
Gold
Nickel
Acetal
Commercial
Panel Jacks, Crimp
11.2
[.441]
Dia.
±0.1
12.7
[.500
±.004
]
17.84
[.702]
±0.1
Max.
12.7
[.500
28.96
[1.140]
Max.
±.004
]
2.77
[.109]
Dia.
Recommended Panel Cutout
Interchangeable Dies
Interchangeable
Dies for Hand
Tool 69710-1
& 626 Pneu.
CERTI-CRIMP
Hand Tool
with
for PRO-CRIMPER
Hand Tool 354940-1
or
Center
Contact
Plating
RG/U
Cable
Termination
Type
Body
Plating
Dielectric
Style
Part No.
Integral Die
PRO-CRIMPER
Adapter 679304-1
Head 318161-1
174, 188, 188A, 316
58, 58A, 58B, 58C
O Crimp
O Crimp
Gold
Gold
Nickel
Nickel
TEFLON MIL Type
—
1424050-1
91901-1
220026-1
69727-
5225397-7
5225397-1
TEFLON MIL Type -69478-1
124, 140, 210, 62, 62A, 62B,
59, 59A, 59B, BELDEN 9291,
9209, 9269, 89269
O Crimp
Gold
Nickel
TEFLON MIL Type -69477-1
258537-1
269669-1
5225397-2
BELDEN is a trademark of Belden Wire
and Cable Company.
TEFLON is a trademark of E.I. Dupont de
Nemours and Company.
Note: Part Numbers are RoHS compliant except:ꢀ Indicates non-RoHS compliant.
52
Catalog 1307191
Revised 3-07
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
