RF Coax Connectors
BNC Connectors, 75 Ohm (Continued)
Bulkhead Solder Jacks
Front Mount
Accepts
.054 Dia.
Max. Wire
Accepts
.054 Dia.
Max. Wire
27.43
[1.083]
Max.
Max.
27.43
[ 1.083]
Plating
Body—Nickel
Center Contact —Silver
3/8-32 Thread
3/8-32 Thread
9.75/9.65
[.384./380]
Dia.
13.09 Dia.
[.515] Max.
13.09 Dia.
[.515] Max.
Part No. 5415187-1
(without Solder Terminal)
Part No. 5221244-1
4.04/3.96
[.159/.156]
(with Solder Terminal)
Maximum Panel Thickness 3.18 [.125]
Note: If insulating bushing required
use part no. 227223-1 or 221951-1
(for details, reference page 55).
Note: If insulating bushing required
use part no. 227223-1 or 221951-1
(for details, reference page 55).
Recommended Panel Cutout
Bulkhead Jack
PC Board Mount
3.30
[.130]
± 0.1
Ø 12.70
[.500
11.07
[.436]
± .004
]
Max.
20.8
[.820]
± 0.1
11.2
[.441
± .004
]
Part No. 6274086-1
Accepts .
.050 Dia.
Max. WIre
Bulkhead Solder Jack
Rear Mount
Lockwasher and Jam Nut see page 73.
12.83+-0.1003
[.505
Dia.
+.005
-.000
17.78 Dia.
[.700] Max.
]
1/2-28 Thread
Plating
Body—Nickel
Center Contact —Gold
5.54+-0.0008
Dielectric
—Polymethylpentene
+.003
[.218
]
31.75
[ 1.250]
-.000
Max.
Maximum Panel Thickness 6.35 [.250]
Recommended Panel Cutout
Part No. 5414217-1
Note: Part Numbers are RoHS compliant except:ꢀIndicates non-RoHS compliant.
71
Catalog 1307191
Revised 3-07
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
