RF Coax Connectors
BNC Connectors, 50 Ohm (Continued)
Terminator Plugs
50, 75, 93 Ohm
Part No.
With Tether
5221629-11
5221629-21
—
Resistor
Specification
Without Tether
5221629-4
5221629-5
5221629-6
—
Tether
Plating
1 Watt, 50 Ohm
1 Watt, 75 Ohm
1 Watt, 93 Ohm
0.5 Watt, 75 Ohm
1 Watt, 50 Ohm
Body—Nickel
Center Contact —Gold
Dielectric —Polyethylene
—
1-5221629-61
—
14.53 Dia.
[.572] Max.
[1.300]
33.02
1 Tether is conductive with #4 stud size
#6 Stud Size
Insulated
Terminators
Long Cover
Insulation Material
Polyphenylene oxide
38.10
[1.500]
38.10
[1.500]
Max.
Max.
17.40
[.685]
17.40
[.685]
Short Cover*
Register
Color
Cover
Style
Part
No.
Specification
Long
Short
Long
5413557-1
5413364-2
5413557-2
Gray
1 Watt, 50 Ohm
Black
* The Short Cover is required when mating the Terminator with a Tee Adapter.
Jack Covers
Shorting Caps
22.10
[.870]
Max.
14.53 Dia.
[.572] Max.
Plating
Body— Nickel
Center Contact —Gold
Body Plating
Silver
Part No.
330022
Nickel
1-330022-2
15.24
[.600]
101.6
[4.000]
14.53
[.572]
#6 Stud Size
Dia. Max.
Part No. 413453-1
Note: Part Numbers are RoHS compliant except:ꢀIndicates non-RoHS compliant.
65
Catalog 1307191
Revised 3-07
Dimensions are in millimeters
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
