RF Coax Connectors
BNC Connectors, 50 Ohm (Continued)
Jacks with
Mounting Flanges
PC Board/Panel Mount
1/2-28 Thread
15.88 [.625]
Mounting Height
12.83+-0.1003
Dia.
+.005
[.505
]
-.000
8.59
C
L
[.338]
21.21
34.93
[1.375]
[.835]
5.54+-0.0008
Dia.
+.003
[.218
]
-.000
Maximum Panel Thickness 6.1 [.240]
Recommended Panel Cutout
Body
Material
Center Contact
Plating
Part No.
Tin
5226978-1
5226978-3
VALOX,
White
Gold
Lockwasher and Jam Nut
3.3 [.130] Dia.
Clearance Hole
for 5-40 Screw
±0.08
22.86
[.900
±.003
]
Mating
Face
8.89
[.350]
11.43
[.450]
Part No.
1-329632-2
Part No.
1-329631-2
2.54
[.100]
G
S
±0.08
0.89
±.003
[.035
]
(Top View)
Recommended PC Board Layout
VALOX is a trademark of General Electric
Company.
Note: Part Numbers are RoHS compliant except:ꢀIndicates non-RoHS compliant.
59
Catalog 1307191
Revised 3-07
Dimensions are in millimeters
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
