General Purpose Relays
Multimode Relay MT
I
I
I
I
I
I
I
2 / 3 pole 10 A, 2 CO or 3 CO contacts
DC and AC coils
Mechanical indicator as standard
Electrical indicator
New test system with front operated finger protected
push-to-test button and integral locking test tab
White write on panel
RoHS compliant (Directive 2002/95/EC)
as per product date code 0415
F0161-A
Applications
Mechanical engineering, plant control
Approvals
V
REG.-Nr.
of
6182,
Z
on request
E214025
Technical data approved types
Contact data
Contact configuration
Contact set
Type of interruption
Rated current
Rated voltage / max.switching voltage AC
Maximum breaking capacity AC
Limiting making capacity, max 20 ms
Contact material
2 CO or 3 CO
single cont.
single cont.
bifurcated
micro disconnection
10 A
10 A
4A
240/400 VAC
2500 VA
2500 VA
500 VA
20 A
20 A
8A
AgNi90/10
AgNi90/10
AgNi90/10
gold plated
gold plated
Minimum contact load
12V/10mA
20mV/1mA
20mV/1mA
Mechanical endurance
20x10
6
cycles
Rated frequency of operation with / without load
20/100 min
-1
Contact
Type
MT321
MT321
MT321
MT3..
MT2..
MT2..
ratings
Load
10 A, 250 VAC, CO contact, cosϕ=1, 360/h, df 50%, 35°C
I
on
50 A, I
off
5 A, 3x440 VAC, NO, cosϕ=0.3, AC15, normal cond.
I
on
30 A, I
off
3 A, 3x440 VAC, NC, cosϕ=0.3, AC15, normal cond.
2 A, 125 V, L/R 30 ms, 3 NO contacts in series, 1800/h, DF 10%
0.7 A, 125 V, L/R 20 ms, 2 NO contacts in series, 1800/h, DF 10%
1 A, 125 V, L/R 20 ms, 2 NO contacts in series, 1800/h, DF 10%
Cycles
2.2x10
5
6x10
3
6x10
3
1x10
5
2x10
5
4x10
4
Coil data
Rated coil voltage range DC coil
AC coil
Coil power DC coil
AC coil
Operative range
6...220 VDC
6...230 VAC
1.2 W
2.3 VA
1
Coil versions, DC-coil
Coil code
Rated
Operate
Release
Coil
Rated coil
STD
PD*)
voltage
voltage
voltage
resistance
power
VDC
VDC
VDC
Ohm
W
006
0A6
6
4.5
0.6
32+10%
1.1
012
0B2
12
9.0
1.2
110+10%
1.3
+
024
0C4
24
18.0
2.4
475+10%
1.2
048
0E8
48
36.0
4.8
2000+10%
1.2
060
0G0
60
45.0
6.0
2850+10%
1.3
110
1B0
110
82.5
11.5
10000+12%
1.2
220
2C0
220
165.0
22.0
40000+15%
1.2
All figures are given for coil without preenergization, at ambient temperature +23°C
*) Protection diode PD; standard polarity: 2-pole relays: +2 / -7, 3-pole relays: +2 / -10
1
Datasheet
Rev. EK1
Issued 2005/11
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information
only to be used together
with the 'Definitions' at
schrackrelays.com in the
‘Schrack’ section.
Specifications subject to
change.
