Raychem Quadlite Cables (Continued)
Product Facts
■ 100 Ohm and 150 Ohm
cables
■ Materials rated from
-85°F to + 392°F
[-65°C to +200°C]
■ Low outgassing materials
(PTFE, FEP)
■ Custom design capabilities
■ Proven technologies and
materials
■ App. Example
C130 = 97' length
= 20-30 meters
100 Ohms - 200˚C
CEC-RWC-18687
100 Ohms - 150˚C
Raychem Part Number
CEC-RWC-18664
Conductor AWG Size (19 Strand)
Conductor Material:
Nom. Conductor Diameter (in.):
24
SCCA
0.0235
24
SCCA
0.0235
Insulation Material:
Nom. Insulation OD 0.002 (in.):
FEP
0.042
FEP
0.042
Nom. Cable OD (in.):
Nom. Cable Weight (lbs/1 kft):
Shield Material:
0.166
0.167
24.7
Flat SCC/Round SCC
FEP
22.9
Alum. MYLAR/Round TCC
FEP
Jacket Material:
Impedance 10ꢀ (Ω):
Temp. Rating:
Nom. Capacitance (pF/ft):
100 Ohms
200˚C
100 Ohms
150˚C
13.0
13.0
100 BASE-T Ethernet
10 MHz 100 MHz
10 MHz 100 MHz
Nom./Max. Attenuation (dB/100 Ft).
Min. NEXT (dB)
Min. SR (dB)
2.3/2.7
47
23
8.0/9.2
32
16
2.3/2.7
47
23
8.0/9.2
32
16
150 Ohms - 200˚C
CEC-RWC-18684
150 Ohms - 150˚C
CEC-RWC-18680
Raychem Part Number
Conductor AWG Size (19 Strand)
Conductor Material:
Nom. Conductor Diameter (in.):
26
SCCA
0.0235
26
SCCA
0.0235
Insulation Material:
Nom. Insulation OD 0.005 (in.):
FEP
0.058
FEP
0.058
Nom. Cable OD (in.):
Nom. Cable Weight (lbs/1 kft):
Shield Material:
0.200
0.201
30.6
Flat SCC/Round SCC
FEP
30.9
Alum. MYLAR/Round SCC
FEP
Jacket Material:
Impedance 10ꢀ (Ω):
Temp. Rating:
Nom. Capacitance (pF/ft):
150 Ohms
200˚C
150 Ohms
150˚C
9.0
9.0
Fiber Channel
Nom./Max. Attenuation (dB/100 Ft).
531 MHz
13
21
3
13
21
3
1062 MHz
Nom. Delay Skew (ps/ft)
