RBV25005-RBV2510
Silicon Bridge Rectifiers
VOLTAGE RANGE: 50 --- 1000 V
CURRENT: 25.0 A
KBJ
Features
Rating to 1000V PRV
30± 0.3
4.7± 0.25
3.7± 0.2
.1
2± 0
5
Surge overload rating to
200
Am peres peak
20± 0.3
5.5± 0.2
Ideal for printed circuit board
Reliable low cos t cons truction utilizing m olded
plas tic technique res ults in inexpens ive product
Lead s olderable per MIL-STD-202 m ethod 208
φ
3 .
11.1± 0.2
2.4± 0.2
4.0± 0.2
2.2± 0.2
1.0± 0.1
17.7± 0.5
2.8± 0.2
0.8± 0.15
Mechanical Data
Polarity:Sym bols m olded on body
Weight:0.23 ounces , 6.6 gram s
Mounting pos ition: Any
10± 0.2 7.5± 0.2 7.5± 0.2
Dimensions in millimeters
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
am bient tem perature unles s otherwis e s pecified.
Single phas e,half wave,60 Hz,res is tive or inductive load. For capacitive load,derate by 20%.
RBV
25005
Maximum recurrent peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average f orw ard
Output current
@T
A
=25
RBV
2501
100
70
100
RBV
2502
200
140
200
RBV
2504
400
280
400
25.0
RBV
2506
600
420
600
RBV
2508
800
560
800
RBV
2510
1000
700
1000
UNITS
V
V
V
A
V
RR M
V
RMS
V
DC
I
F(AV)
50
35
50
Peak forw ard surge current
8.3ms single half-sine-w ave
superimposed on rated load
Maximum instantaneous f orw ard voltage
at 12.5 A
Maximum reverse current
at rated DC blocking voltage
@T
A
=25
@T
A
=100
I
FSM
300
A
V
F
I
R
C
J
R
θJC
T
J
T
STG
1.1
10.0
0.2
85
0.6
- 55 ---- + 150
- 55 ---- + 150
V
μA
mA
pF
/W
Typical junction capacitance per element
Typical thermal resistance
Operating junction temperature range
Storage temperature range
NOTES:1.Measured at 1.0MH
Z
and applied rev erse v oltage of 4.0V DC
2.Dev ice mounted on 300mm X 300mm X 1.6mm cu Plate heatsink.
