LTC1629/LTC1629-PG
U
PACKAGE DESCRIPTIO
Dimensions in inches (millimeters) unless otherwise noted.
G Package
28-Lead Plastic SSOP (0.209)
(LTC DWG # 05-08-1640)
10.07 – 10.33*
(0.397 – 0.407)
28 27 26 25 24 23 22 21 20 19 18
16 15
17
7.65 – 7.90
(0.301 – 0.311)
5
7
8
1
2
3
4
6
9 10 11 12 13 14
5.20 – 5.38**
(0.205 – 0.212)
1.73 – 1.99
(0.068 – 0.078)
0° – 8°
0.65
(0.0256)
BSC
0.13 – 0.22
0.55 – 0.95
(0.005 – 0.009)
(0.022 – 0.037)
0.05 – 0.21
(0.002 – 0.008)
0.25 – 0.38
(0.010 – 0.015)
NOTE: DIMENSIONS ARE IN MILLIMETERS
*DIMENSIONS DO NOT INCLUDE MOLD FLASH. MOLD FLASH
SHALL NOT EXCEED 0.152mm (0.006") PER SIDE
**DIMENSIONS DO NOT INCLUDE INTERLEAD FLASH. INTERLEAD
FLASH SHALL NOT EXCEED 0.254mm (0.010") PER SIDE
G28 SSOP 1098
