DEMO MANUAL DC2026A
Quick start GuiDe
Running with QuikEval
Linear Technology demo boards with the 14-pin QuikEval
connector are normally used in conjunction with a DC590B
interface board and the QuikEval software package running
on a PC. Designers can then use the software to evaluate
the performance of the product on the demo board. The
Linduino One comes programmed with firmware that al-
lows it to emulate the DC590B controller, so the QuikEval
software can be used to check basic functionality in a
target system.
Connect the DC934 to the Linduino One with the supplied
14-pin ribbon cable. Run QuikEval. The control panel for
the LTC2607 will appear, and clicking COLLECT will start
communication with the board. The onboard LTC2422
ADC reads back the output voltages, and the voltage may
be changed by entering a number in the appropriate box
or by moving the sliders.
Quit QuikEval after this step.
