Data Sheet
GE
QBVW025A0B Barracuda™ Series; DC-DC Converter Power Modules
36-75Vdc Input; 12.0Vdc, 25.0A, 300W Output
Mechanical Outline for QBVW025A0B Through-hole Module
Dimensions are in millimeters and [inches].
Tolerances: x.x mm 0.5 mm [x.xx in. 0.02 in.] (Unless otherwise indicated)
x.xx mm 0.25 mm [x.xxx in 0.010 in.]
*Top side label includes GE name, product designation, and data code.
** Standard pin tail length. Optional pin tail lengths shown in Table 2, Device Options.
TOP VIEW*
SIDE VIEW
BOTTOM VIEW
Pin
Pin
Number Name
1*
2*
3*
4*
5†
6†
7†
8*
VIN(+)
ON/OFF
VIN(-)
VOUT(-)
SENSE(-)
TRIM
SENSE(+)
VOUT(+)
† - Optional Pins
See Table 2
May 9, 2013
©2012 General Electric Company. All rights reserved.
Page 14
