KEMET®
TANTALUM DIPPED / RADIAL — MIL-C-49137/2
T363 (CX02), T369 (CX12) SERIES
Product manufactured to the requirements of MIL-C-49137 satisfy
all the performance characteristics of the UltraDip II. The perfor-
mance characteristics meet or exceed the requirements of MIL-C-
49137.
for Group A and Group B inspection to insure compliance. Product
supplied per MIL-C-49137 also receives an additional post process
burn-in for at least two (2) hours under accelerated voltage stress in
excess of 125% of DC rated voltage. This post process burn-in is
equivalent to 200 hours under rated conditions.
In addition to the standard process testing done on the UltraDip II,
all product supplied to MIL-C-49137 is sampled on a lot by lot basis
CAPACITOR OUTLINE DRAWINGS
DIMENSIONS — INCHES & (MILLIMETERS)
T363 A-D CASE
T363 (CX02)
A, B, C & D CASES
T369 (CX12)
T369 A&B CASE ONLY
A & B CASES
.250 ± .025
CASE
SIZE
D MAX
H MAX
D
(6.35 ± .64)
D
MAX.
MAX.
0.175
(4.45)
0.350
(8.89)
A
B
C
D
H
H
A & B
MAX.
MAX.
.020 ± .002
(.51 ± .05)
C & D
0.250
(6.35)
0.450
(11.43)
.025 ± .002
(.64 ± .05)
.020 ± .002
(.51 ± .05)
.187 ± .032
(4.75 ± .81)
.187 ± .032
(4.75 ± .81)
0.350
(8.89)
0.610
(15.49)
.125 ± .015
(3.18 ± .38)
0.400
(10.16)
0.740
(18.80)
.250 ± .015
(6.35 ± .38)
MIL-C-49137 MARKING INFORMATION
Mfg. - KEMET
Voltage
Capacitance Tolerance
Capacitance
(in Picofarad Code)
Date
Code
Polarity
MIL-C-49137/2 ORDERING INFORMATION
CX
02
D
225
K
TYPE
CAPACITANCE TOLERANCE
Capacitors, Fixed, Solid Tantalum
Conformal Coated, Non-hermetically Sealed.
Symbol
Capacitance Tolerance
Percent (±)
STYLE
02 (T363) A, B, C & D Cases
12 (T369) A & B Cases Only
K
M
10
20
CAPACITANCE IN PICORARAD CODE
The nominal capacitance value, expressed in
picofarads (pF), is identified by a three-digit number;
the first two digits represent significant figures and
the last digit specifies the number of zeros to follow.
VOLTAGE
Symbol
Rated (857C)
Volts, dc
Surge (857C)
Volts, dc
D
F
H
J
K
M
N
6
8
10
15
20
25
35
50
13
20
26
32
46
65
*For KEMET Ordering Information, see page 63.
66
