KEMET®
TANTALUM MOLDED / RADIAL — MIL-C-49137/6
T370/T378 (CX06) SERIES
RATINGS & PART NUMBER REFERENCE
CAPACITANCE
µF
CASE
SIZE
INDUSTRIAL PRODUCT
T370
MILITARY PRODUCT
DC LEAKAGE
µA@25°C
DISSIPATION FACTOR
%@25°C 120HZ
MAXIMUM
CXO6
T378
PART NO.
PART NO.
PART NO.
MAXIMUM
3 VOLT RATING AT 85°C—2.0 VOLT RATING AT 125°C
220.0
F
T370F227(1)003AS
CX06B227(2)
T378F227(3)003AS
9.0
15
4 VOLT RATING AT 85°C—2.7 VOLT RATING AT 125°C
15.0
47.0
68.0
C
D
E
T370C156(1)004AS
T370D476(1)004AS
T370E686(1)004AS
1.0
2.0
3.0
8
8
8
CX06C476(2)
CX06C686(2)
T378D476(3)004AS
T378E686(3)004AS
6 VOLT RATING AT 85°C—4.0 VOLT RATING AT 125°C
10.0
33.0
47.0
C
D
E
F
T370C106(1)006AS
T370D336(1)006AS
T370E476(1)006AS
T370F157(1)006AS
1.0
6
6
6
CX06D336(2)
CX06D476(2)
CX06D157(2)
T378D336(3)006AS
T378E476(3)006AS
T378F157(3)006AS
2.0
3.0
9.0
150.0
10
10 VOLT RATING AT 85°C—7.0 VOLT RATING AT 125°C
6.8
22.0
33.0
C
D
E
F
T370C685(1)010AS
T370D226(1)010AS
T370E336(1)010AS
T370F107(1)010AS
1.0
2.0
3.0
9.0
6
6
6
8
CX06F226(2)
CX06F336(2)
CX06F107(2)
T378D226(3)010AS
T378E336(3)010AS
T378F107(3)010AS
100.0
15 VOLT RATING AT 85°C—10 VOLT RATING AT 125°C
15.0
22.0
68.0
D
E
F
T370D156(1)015AS
T370E226(1)015AS
T370F686(1)015AS
CX06H156(2)
CX06H226(2)
CX06H686(2)
T378D156(3)015AS
T378E226(3)015AS
T378F686(3)015AS
2.0
3.0
9.0
6
6
8
20 VOLT RATING AT 85°C—13 VOLT RATING AT 125°C
3.3
4.7
10.0
15.0
47.0
C
C
D
E
F
T370C335(1)020AS
T370C475(1)020AS
T370D106(1)020AS
T370E156(1)020AS
T370F476(1)020AS
1.0
6
6
6
6
8
1.0
2.0
3.0
9.0
CX06J106(2)
CX06J156(2)
CX06J476(2)
T378D106(3)020AS
T378E156(3)020AS
T378F476(3)020AS
25 VOLT RATING AT 85°C—17 VOLT RATING AT 125°C
2.2
6.8
10.0
33.0
C
D
E
F
T370C225(1)025AS
T370D685(1)025AS
T370E106(1)025AS
T370F336(1)025AS
1.0
6
6
6
6
CX06K685(2)
CX06K106(2)
CX06K336(2)
T378D685(3)025AS
T378E106(3)025AS
T378F336(3)025AS
2.0
3.0
9.0
35 VOLT RATING AT 85°C—23 VOLT RATING AT 125°C
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10.0
15.0
22.0
C
C
C
D
D
D
E
F
T370C684(1)035AS
T370C105(1)035AS
T370C155(1)035AS
T370D225(1)035AS
T370D335(1)035AS
T370D475(1)035AS
T370E685(1)035AS
T370F106(1)035AS
T370F156(1)035AS
T370F226(1)035AS
1.0
6
6
6
6
6
6
6
6
6
6
1.0
1.0
2.0
2.0
2.0
3.0
9.0
9.0
9.0
CX06M225(2)
CX06M335(2)
CX06M475(2)
CX06M685(2)
CX06M106(2)
CX06M156(2)
CX06M226(2)
T378D225(3)035AS
T378D335(3)035AS
T378D475(3)035AS
T378E685(3)035AS
T378F106(3)035AS
T378F156(3)035AS
T378F226(3)035AS
F
F
(1) To complete KEMET part number, insert capacitance tolerance symbol as follows: L = ±40%, –20%; M = ±20%; K = ±10%; J = ±5%.
(2) To complete military part number, insert capacitance tolerance symbol as follows: M = ±20%; K = ±10%.
(3) To complete KEMET part number, insert cpapacitance tolerance symbol as follows: M = ±20%; K = ±10%.
60
