JMK Inc
The AA-1355-6.3 filter has been designed to operate with the
VICOR Harmonic Attenuator Module (HAM). This filter was spe-
cifically designed to allow the Vicor HAM and
associated power converters to meet Mil-Std-461C or
Mil-Std-461D & E.
The Standard enclosure mounting, and pin configuration are
identical to the enclosure for the standard HAM filter.
This version of the filter is configured for those applications
where a chassis mount for the filter is preferred.
Transient protection has been added to the filter.
The HAM will meet Mil-Std-461C with the AA-1355-6.3. Addi-
tional circuitry is required on the input in order to meet
Mil-Std-461E.
AA-1355-6.3
Operating voltage________________85 to 250 V~
Operating current ________________6.3 Amp
Operating frequency______________50/400 Hz
Operating temperature, High________50ºC
Operating temperature, Low ________-20º C,
Diel. withstanding (line - case)____1500 Vac
Diel. withstanding (line - line)_____1500 Vdc
Leakage current__________________2.5 ma @ 220 V, 60 Hz
Max residual voltage after 1 sec__ 34 Volts
Applicable Specifications________Mil-Std-461C
Mil-Std-461E
USA
EUR
JMK Inc 15 Caldwell Dr. Amherst, NH 03031
PH: 603 886-4100
FX: 603 886-4115 email: info@jmkfilters.com
JMK Inc Glasgow G13 1DN Scotland UK PH: 44-(0) 7785310729 FX: 44-(0) 141-589-1884
JMK [ JMK INC. ]
