Micro Center Jackscrew
Plug (Molded-In Insert - Special)
MJS
MJSV**P
A
INSERT
#1-64 UNC-2B
MAX.
CAVITY # 1
ENGAGING FACE
MICRO-PIN
CONTACT
INSULATOR
.100 (2.54)
.300 (7.62)
MAX.
.162 (4.11)
REF.
LEAD
LENGTH
.061 (1.55)
MAX.
A
Max.
.109 (2.77)
MAX. DIA.
Part Number
MJSV-26P**
MJSV-38P**
.868 (22.05)
MJSV-26P**
(Shown)
1.168 (29.67)
Receptacle (Special)
MJSV**S*
A
MAX.
MICRO-SOCKET
.100 (2.54)
REF.
#1-64 UNC-2A
CAVITY # 1
.190 (4.83)
REF.
.320 (8.13)
MAX.
.253 (6.43)
MAX.
.167 (4.24)
REF.
.155 (3.94)
MAX.
B
LEAD
LENGTH
A
Max.
B
Max.
JACKSCREW
Part Number
MJSV-26S**
(Shown)
MJSV-26S**
MJSV-38S**
.943 (23.95)
.874 (22.20)
1.243 (31.57)
1.174 (29.82)
Contact Arrangements
Face view of pin - use reverse order for socket
.100 (2.54)
.100 (2.54)
REF.
.050 (1.27)
.075 (1.91)
.075 (1.91)
14
1
20
1
+
+
38
21
15
26
.050 (1.27)
TYP.
.050 (1.27)
TYP.
26 Contacts
38 Contacts
Identification numbers are for reference and do not appear on connectors.
Dimensions shown in mm
Specifications and dimensions subject to change
www.ittcannon.com
57
