Micro-D Metal Shell Low Profile 0.50” Spacing
How to Order | Part Number Nomenclature – Slash Sheets 1-5, 10-27
MDLM
MDLM
-
25
P
6
P
Y
18
L
-
A174
Series
MDLM - MDM Low Profile
Contact Arrangement
9, 15, 21, 25, 31, 37 & 51
Contract Type
P
S
-
-
Pin
Socket
Wire Gauge (AWG)
4
6
8
0
-
-
-
-
#24 Gauge
#26 Gauge (Standard)
#28 Gauge
#30 Gauge
Wire Type
P
T
E
C
-
-
-
-
Teflon(PTFE) Wire Per MIL-W-16878/4 (Standard)
Teflon(TFE) Wire Per MIL-W-22759/11
Cross-Linked Tefzel(ETFE) Wire Per MIL-W-22759/33
Custom Wiring
Wire Colour
W
Y
S
T
C
-
-
-
-
-
White
Yellow (Standard)
Color Coded pet MIL-STD-681, System 1
Ten Color Repeat
Custom Wire Coloring
Overall Wire Length (Inches)
1 Inch Minimum and Must be Rounded to the Nearest Whole Inch
Examples:
-
-
-
-
-
5 - 5 inches
18 - 18 inches
50 - 50 inches
120 - 120 inches
Custom Wire Lengths
C
Hardware
B
A
P
K
L
-
-
-
-
-
-
No hardware, Ø.091 Hole
No hardware, Ø.125 Hole
Jackpost
Jackscrew-Standard
Jackscrew-Low Profile
Float Mount
Military Specification Hardware
M2 - Jackscrew-low profile (Allen Head)
M3 - Jackscrew-standard profile (Allen Head)
M5 - Jackscrew-low profile (Slotted Head)
M6 - Jackscrew-standard profile (Slotted Head)
M7 - Jackpost
F
Shell Finish/Mod Codes
No
Number- Electroless Nickel (RoHS Compliant)
A101
A172
A141
A30
-
-
-
-
Yellow Chromate/Cadmium over Nickel (Not RoHS Compliant)
Gold over Nickel (RoHS Compliant)
Irridite/Alodine (RoHS Compliant)
Black Anodize (RoHS Compliant)
(Consult Factory for all other Mod Codes)
Dimensions shown in mm
Specifications and dimensions subject to change
